Discover ION
Discover ION
We didn’t invent the electric outboard motor…
We simply perfected it.
We set out by listening to boaters who desired more from their cruising experience. They envisioned a premium, more stylish electric outboard motor that didn’t compromise performance or luxury. Taking their feedback to heart, our engineers went to work, handcrafting a marine propulsion system exclusively developed to meet your needs while evoking serenity and sophistication with thoughtful design. Handcrafted and assembled in Michigan, each ION product reflects our unwavering dedication to excellence.
Consider ION your official invitation to unwind, recharge, and live more of life in the moment.
We didn’t invent the electric outboard motor…
We simply perfected it.
We set out by listening to boaters who desired more from their cruising experience. They envisioned a premium, more stylish electric outboard motor that didn’t compromise performance or luxury. Taking their feedback to heart, our engineers went to work, handcrafting a marine propulsion system exclusively developed to meet your needs while evoking serenity and sophistication with thoughtful design. Handcrafted and assembled in Michigan, each ION product reflects our unwavering dedication to excellence.
Consider ION your official invitation to unwind, recharge, and live more of life in the moment.
Thoughtful Features
With You In Mind
Thoughtful Features With You In Mind
ENJOY THE CONVENIENCE OF KEYLESS ACTIVATION THROUGH ION VUE, ITS INTUITIVE, BUILT-IN TOUCH SCREEN DISPLAY, SO YOU NEVER HAVE TO WORRY WHERE YOUR KEYS ARE. JUST SET A PERSONALIZED, SECURE PASSCODE – AND GO.
Thoughtful Features
With You In Mind
Thoughtful Features
With You In Mind
EXPERIENCE THE CONVENIENCE OF KEYLESS ACTIVATION THROUGH ION VUE, ITS INTUITIVE, BUILT-IN TOUCH SCREEN DISPLAY, SO YOU NEVER HAVE TO WORRY WHERE YOUR KEYS ARE. JUST SET A PERSONALIZED, SECURE PASSCODE – AND GO.
Embrace
Modern Control
Embrace
Modern Control
THE ION 6 IS EQUIPPED WITH ION VUE, ITS OWN FULLY INTEGRATED TOUCHSCREEN DISPLAY. THIS INTUITIVE INTERFACE MAKES NAVIGATING YOUR JOURNEY EASIER THAN EVER.
Embrace
Modern Control
Embrace Modern Control
The ION 6 is equipped with its own fully integrated Touch Screen Helm display. Experience the intuitive interface that makes vessel operation smoother than ever.
Seamless Cruising,
No Sweat
Seamless Cruising, No Sweat
We’ve got it covered! The ION 6 comes with integrated hydraulic tilt and trim, making it easier than ever to adjust with precision and enjoy a more comfortable, carefree ride.
Seamless Cruising,
No Sweat
Seamless Cruising, No Sweat
We’ve got it covered! The ION 6 comes with integrated hydraulic tilt and trim, making it easier than ever to adjust with precision and enjoy a more comfortable, carefree ride
Vessel
Versatility
Vessel
Versatility
From saltwater to freshwater and with options for shaft lengths, propellers, and throttle mounts, the ION 6 will elevate your boating experience, no matter how you cruise.
Vessel
Versatility
Vessel
Versatility
From saltwater to freshwater and with options for shaft lengths, propellers, and throttle mounts, the ION 6 will elevate your boating experience, no matter how you cruise.
Match the mood
of the moment
Match the mood
of the moment
ION 6’S SIGNATURE LED LIGHT REDEFINES STYLE FOR ELECTRIC OUTBOARDS. USE ION AURA TO CREATE THE PERFECT SCENE WITH A CUSTOM RANGE OF COLORS – FROM RED, TO WHITE, TO RAINBOW! SPARK EXCITEMENT WITH PROGRAMMABLE LIGHTING SETTINGS AND TURN EVERY OUTING INTO A DAZZLING DISPLAY.
Match the mood
of the moment
Match the mood
of the moment
The ION 6’s signature LED light redefines style for electric outboards. Create the perfect scene with a range of colors from red to white to rainbow! Spark excitement with customizable lighting settings and turn every outing into a dazzling display.
ION SPECIFICATIONS
ION SPECIFICATIONS
- Power: 6kW
- Voltage: 48V
- Weight: 32 KG (70 LBS)
- Propeller Options:
- Three Blade 10.8″ Pitch Standard
- Optional Five Blade 8.4″ Pitch Available
- Tilt and Trim Device: Integrated Electric Hydraulic
- Tilt Angle: 9 to 73° (64° range)
- Shaft Lengths
- S: 63.7 CM (25”)
- L: 76.4 CM (30”)
- XL: 88.9 CM (35”)
- Control: Remote Throttle
- Motor Style: Brushless DC
- Direct Drive: Yes
- Warranty: 2 Years / 1 Year Commercial
ION SPECIFICATIONS
ION SPECIFICATIONS
- Power: 6kW
- Voltage: 48V
- Weight: 32 KG (70 LBS)
- Propeller Options:
- Three Blade 10.8″ Pitch Standard
- Optional Five Blade 8.4″ Pitch Available
- Tilt and Trim Device: Integrated Electric Hydraulic
- Tilt Angle: 9 to 73° (64° range)
- Shaft Lengths
- S: 63.7 CM (25”)
- L: 76.4 CM (30”)
- XL: 88.9 CM (35”)
- Control: Remote Throttle
- Motor Style: Brushless DC
- Direct Drive: Yes
- Warranty: 2 Years / 1 Year Commercial
| BATTERY TECHNICAL DATA | |
|---|---|
| CELL CHEMISTRY (LITHIUM ION) | NMC |
| DIMENSIONS (L X W X H) (MM) | 435 X 307 X 182 |
| VOLTAGE NOMINAL (V) | 50.4 |
| VOLTAGE MAXIMAL (V) | 58.8 |
| VOLTAGE MINIMAL (V) | 35 |
| CONTINUOUS DISCHARGE CURRENT (A) | 220 |
| DISCHARGE CURRENT MAX. (A) | 320 |
| ENERGY (KWH) | 4.4 |
| MASS (KG) | 32 |
| CELL TEMP. DISCHARGING (C) | -20 TO 55 |
| CELL TEMP. CHARGING (C) | 0 TO 55 |
| COMMUNICATION | CAN BUS |
| PROTECTION CLASS (EN 60529) | IP65 |
BATTERY SPECIFICATIONS
BATTERY SPECIFICATIONS
- Rechargeable batteries with high quality Lithium-ion cells
- Intelligent control through advanced battery management system (BMS)
- Monitoring of individual cell voltages
- protection against cell under and overcharging
- equalization of individual cell voltages
- cell temperature monitoring
- Integrated safety shut-off redundancy including power contacts, fuse, pre-charge check and current sensors
- Industrial plugs for easy and safe connection, quickswap capability
- Integrated active heater allows high charging and discharging rates at ambient temperatures below 0°C
- Robust aluminum housing protection class IP65
- 3 Year Warranty
BATTERY SPECIFICATIONS
BATTERY SPECIFICATIONS
- Rechargeable batteries with high quality Lithium-ion cells
- Intelligent control through advanced battery management system (BMS)
- Monitoring of individual cell voltages
- protection against cell under and overcharging
- equalization of individual cell voltages
- cell temperature monitoring
- Integrated safety shut-off redundancy including power contacts, fuse, pre-charge check and current sensors
- Industrial plugs for easy and safe connection, quickswap capability
- Integrated active heater allows high charging and discharging rates at ambient temperates below 0°C
- Robust aluminum housing protection class IP65
- 3 Year Warranty
| BATTERY TECHNICAL DATA | |
|---|---|
| CELL CHEMISTRY (LITHIUM ION) | NMC |
| DIMENSIONS (L X W X H) (MM) | 435 X 307 X 182 |
| VOLTAGE NOMINAL (V) | 50.4 |
| VOLTAGE MAXIMAL (V) | 58.8 |
| VOLTAGE MINIMAL (V) | 35 |
| CONTINUOUS DISCHARGE CURRENT (A) | 220 |
| DISCHARGE CURRENT MAX. (A) | 320 |
| ENERGY (KWH) | 4.4 |
| MASS (KG) | 32 |
| CELL TEMP. DISCHARGING (C) | -20 TO 55 |
| CELL TEMP. CHARGING (C) | 0 TO 55 |
| COMMUNICATION | CAN BUS |
| PROTECTION CLASS (EN 60529) | IP65 |
PERFORMANCE AND RANGE
PERFORMANCE AND RANGE
ION 6 offers impressive range, allowing for extended travel on a single battery charge.
| RUNTIME (HH:MM) | RANGE (MILES) | |
|---|---|---|
| FULL THROTTLE | 00:40 | 9.3 |
| HALF THROTTLE | 04:00 | 17.6 |
| SLOW SPEED | 11:26 | 34.3 |
As tested on a Highfield 360e with Ilmor ION battery pack. Actual run time and range will vary based on conditions and boat setup.
